Architecture ARM
CPU EN7562CT
CPU core count 2
CPU nominal frequency 950 MHz
Switch chip model EN7562CT
Dimensions 113x89x28mm
RouterOS license 4
Operating System RouterOS v7
Size of RAM 512 MB
Storage size 128 MB
Storage type NAND
MTBF Approximately 100'000 hours at 25C
Tested ambient temperature -40°C to 70°C

Powering
Details
Number of DC inputs 2 (DC jack, PoE-IN)
DC jack input Voltage 12-28 V
Max power consumption 10 W
Max power consumption without attachments 4 W
Cooling type Passive
PoE in Passive PoE
PoE in input Voltage 12-28 V
Ethernet
Details
10/100/1000 Ethernet ports 5
Peripherals
Details
Number of USB ports 1
USB Power Reset Yes
USB slot type USB type A
Max USB current (A) 1
Other
Details
CPU temperature monitor Yes
PCB temperature monitor Yes
Voltage Monitor Yes
Mode button Yes
