Mechanical
Dimensions 358 x 271.95 x 272.5 mm (14.1 x 10.7 x 10.7")
Weight Without mount: 800 g (1.8 lb)
With mount 980 g (2.2 lb)
Wind survivability 200 km/h (125 mph)
Wind loading 275 N at 200 km/h (61.8 lbf at 125 mph)

Hardware
Networking interface (1) GbE RJ45 port
Power method Passive PoE 2-pair (4, 5+; 7, 8 return)
Power supply 24V, 0.3A gigabit PoE adapter (Included)
Supported voltage range 22–27V DC
Max. power consumption 7W
Max. power output 25 dBm
Gain 23 dBi
Ambient operating temperature -40 to 70° C (-40 to 158° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
NDAA Compliant Yes


Operating Frequency (MHz)
Worldwide 5150-5875 MHz
USA
U-NII-1
U-NII-2A
U-NII-2C
U-NII-3
5150-5250 MHz
5250-5350 MHz
5240-5725 MHz
5725-5850 MHz


Management Radio (MHz)
Worldwide 2412 - 2472 MHz
US/CA 2412 - 2462 MHz
